PE Coated Metallized Film

PE Coated Metallized Film is a high-barrier, heat-sealable metallized film that pairs an aluminum-vapor-deposited PET base with an extrusion-coated polyethylene layer — engineered for laminates that protect flavor, extend shelf life and seal cleanly on high-speed lines.

WVTR < 0.5 g/m²·day · OTR < 1.0 cm³/m²·day (typical)
Integrated PE heat-sealable side
Roll width up to 2750 mm, custom slit
Custom metallization & PE coat weight

Quantity:

库存： 0

Inquire

Description

Overview

PE Coated Metallized Film is a co-extruded flexible packaging web that combines two functional layers in a single, converter-ready roll. A metallized polyester (VM-PET) substrate carries a vacuum-deposited aluminum layer for light, oxygen and aroma barrier, while a polyethylene (PE) coating applied by extrusion lamination forms the inner sealant layer of the finished pouch or sachet.

Because the PE layer is already integrated, converters can laminate the film directly to a print web and run horizontal or vertical form-fill-seal (HFFS / VFFS) without a separate sealant film. The PET base adds high tensile strength, dimensional stability and temperature resistance that polypropylene cannot match — making the structure suitable for hot-fill and retort-compatible laminates when paired with the right PE grade.

Available in widths up to 2750 mm, the film is supplied slit-to-order.

Key Features

High Barrier Performance

Excellent resistance to moisture, oxygen, light and aroma.

Reliable Heat Sealing

Integrated PE sealant layer provides strong and consistent heat sealing.

High Mechanical Strength

PET substrate delivers excellent tensile strength, stiffness and dimensional stability.

Low WVTR & OTR

Helps protect sensitive products and extend shelf life.

Excellent Processing Stability

Low neck-in and stable dimensions support smooth converting and clean slitting.

Customizable PE Coating

Available in 15–40 g/m² coating weights for different sealing requirements.

Flexible Lamination Options

Compatible with solvent-free, solvent-based and extrusion lamination.

Lightweight Foil Alternative

Lower material weight and freight costs compared with conventional aluminum foil laminates.

Product Specifications

Structure	Total Thickness (μm)	PE Coat (μm)	Roll Width	Reflectivity
VM-PET6 / PE	16–60 μm	2–8	Up to 2750 mm	97%
VM-PET8 / PE	16–60 μm	3–10	Up to 2750 mm	97%
VM-PET10 / PE	16–60 μm	5–12	Up to 2750 mm	97%
VM-PET12 / PE	16–60 μm	5–20	Up to 2750 mm	97%
Customized	Depends on material requirements		Up to 2750 mm	97%

Applications

Business Scenarios

Flexible packaging converters and laminators
Contract packers running HFFS / VFFS lines
Distributors of converted rollstock and pouches

Material Guidance

Vacuum-deposited aluminum layer provides light and aroma barrier
PE coating forms the heat-seal layer of the finished pack
White PE variant adds opacity for light-sensitive products

Coating & Lamination Guidance

Standard LDPE / LLDPE coating for general sealability and cost
Co-extruded or metallocene PE options for lower seal-initiation temperature
Corona/flame treatment on the PE side for print and adhesive adhesion
Compatible with solvent-free, solvent-based and extrusion lamination
